Sockel

LGA 1700

Chipset

Intel H610

M.2-platser

1

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

1 x M.2 Socket (Key E), supports PCIe type 2230 WiFi module.

SATA-portar

2

Ljudkodek

Realtek ALC269

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR4

Displayutgångar

Intel Xe Graphics Architecture (Gen 12) / Four graphics output options: 2 x HDMI, 1 x LVDS, 1 x D-Sub ports / Supports 2 x HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60HzHDMI x 1 port (Rear)HDMI x 1 port (Internal) / DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz(optional) / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports LVDS with max. resolution up to 1920x1080 @ 60Hz / Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support

Connector

1 x Chassis Intrusion Header / 1 x Panel Voltage Selection Header / 1 x Backlight Inverter Voltage Selection Header / 1 x FPD Brightness Header / 1 x Panel Off Header / 1 x LVDS Connector / 1 x CPU Fan Connector (4-pin)* / 1 x 4 pin 19V Power Connector (2-Pin) / 1 x Thermal Sensor Header / 1 x Front Panel Audio Connector / 1 x Internal Speaker Header (4-Pin) / 1 x Digital MIC Header / 2 x SATA Power Connectors / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

Accessories

I/O Shield (optional) / 1 x SATA Data Cable (optional) / 1 x SATA Power Cable (optional) / 3 x Screws for M.2 Sockets / 1 x Standoff for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter) / 1 x D-Sub Port**(optional) 1 x COM Port / 2 x HDMI Ports: HDMI1 (Rear), HDMI2 (Internal)****(optional) 1 x DisplayPort 1.4 / 1 x USB 3.2 Gen2 Type-A Port (Supports ESD Protection)*** / 1 x USB 3.2 Gen2 Type-C Port (Supports ESD Protection)******(optional) 2 x USB 3.2 Gen2 Type-A Ports (Supports ESD Protection) / 2 x USB 2.0 Ports (Support ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line out / Microphone

Unique Feature

ASRock Super Alloy / High Density Glass Fabric PCBASRock Blazing M.2 (PCIe Gen5 x4)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)H/W TPM 2.0 IC (optional)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
