Sockel

LGA 1200

Chipset

Intel H510

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

SATA-portar

2

Ljudkodek

Realtek ALC269

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR4

Displayutgångar

11th Gen Intel Core Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core Processors support Gen 9 Graphics / Four graphics output options: 2 x HDMI, 1 x LVDS, 1 x D-Sub ports / Supports 2 x HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz with 11th Gen Intel Core Processors / Supports 2 x HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz with 10th Gen Intel Core ProcessorsHDMI x 1 port (Rear)HDMI x 1 port (Internal)** / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required) / Supports LVDS with max. resolution up to 1920x1080 @ 60Hz / Supports HDCP 2.3 with HDMI 2.0 Port / Supports HDCP 2.2 with HDMI Port (HDCP 2.3 ready with 11th Gen Intel Core Processors)*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.Graphics specifications may vary between CPU types.**(optional) DisplayPort 1.4 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support

Connector

1 x Chassis Intrusion Header / 1 x Panel Voltage Selection Header / 1 x Backlight Inverter Voltage Selection Header / 1 x FPD Brightness Header / 1 x Panel Off Header / 1 x LVDS Connector / 1 x CPU Fan Connector (4-pin)* / 1 x 4 pin 19V Power Connector (2-Pin) / 1 x Thermal Sensor Header / 1 x Front Panel Audio Connector / 1 x Internal Speaker Header (4-Pin) / 1 x Digital MIC Header / 2 x SATA Power Connectors / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

Accessories

I/O Shield (optional) / 1 x SATA Data Cable (optional) / 1 x SATA Power Cable (optional) / 2 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter) / 1 x D-Sub Port* / 2 x HDMI Ports: HDMI1 (Rear), HDMI2 (Internal)** / 1 x USB 3.2 Gen1 Type-C Ports (Supports ESD Protection), 3 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)*** / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line out / Microphone*(optional) 1 x COM Port**(optional) 1 x DisplayPort 1.4***(optional) 4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)

Unique Feature

ASRock Super Alloy / Matte Black PCB / High Density Glass Fabric PCBASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)H/W TPM 2.0 IC (optional)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
