Sockel

LGA 1200

Chipset

Intel H470

M.2-platser

1

Max minne

64 GB

PCIe-platser

Intel 11th Gen & 10th Gen Processors: / 1 x PCIe 4.0 x16 Slot (PCIE1)*Intel H470 Chipset: / 1 x PCIe 3.0 x1 Slot (PCIE2)*** Intel 11th Gen Processors support PCIe 4.0 x16 Intel 10th Gen Processors support PCIe 3.0 x16** Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC897

Dimensioner

231 × 187mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

2 x HDMIIntel 11th Gen Processors support HDMI 2.0, HDCP 2.3 and max. resolution up to 4K 60HzIntel 10th Gen Processors support HDMI 1.4, HDCP 2.3 and max. resolution up to 4K 30Hz* Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Graphics specifications may vary between CPU types.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

USB

6 x USB 3.2 Gen1 (4 Rear, 2 Front) / 6 x USB 2.0 (2 Rear, 4 Front)* All USB ports support ESD Protection

BIOS

128Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

Connector

1 x SPI TPM Header / 1 x Chassis Intrusion and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)*CPU_FAN1 supports the fan power up to 1A (12W).** CHA_FAN1~2/WP support the fan power up to 2A (24W). CHA_FAN1~2/WP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

1 x User Manual / 1 x I/O Shield / 2 x SATA Data Cables / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse/Keyboard Port / 2 x HDMI Ports / 2 x USB 2.0 Ports / 4 x USB 3.2 Gen1 Ports / 1 x RJ-45 LAN Port / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

Rock-Solid Durability / 4 Power PhaseEZ Update / ASRock Auto Driver Installer

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning)UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
