Sockel

LGA 1200

Chipset

Intel H510

Max minne

32 GB

PCIe-platser

6 x PCI Express 3.0 x16 Slots (PCIE1 at x16 / PCIE2~6 at x1) / 1 x Mining Port (M_Port1 at x1)**Support USB Type Riser kitDO NOT install USB device on Mining Port (M_Port1), it is designed for x1 USB riser kit only.

SATA-portar

1

Dimensioner

501 × 224mm

Minnestyp

DDR4

Minnesplatser

1

Displayutgångar

11th Gen Intel Core Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core Processors support Gen 9 Graphics / Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz with 11th Gen Intel Core Processors / Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz with 10th Gen Intel Core Processors / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required) / Supports HDCP 2.2 with HDMI Port (HDCP 2.3 ready with 11th Gen Intel Core Processors)*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.Graphics specifications may vary between CPU types.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit / Linux: Ubuntu 16.04 LTS / Fedora 25**Linux O/S basic function support only, due to the compatibility of the Linux system itself, there is no guarantee that all functions are supported.

BIOS

128Mb AMI UEFI Legal BIOS with multilingual GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support / CPU Core/Cache, CPU GT, VCCSA, DRAM, VCCIO, VCCIN AUX Voltage Multi-adjustment

Connector

1 x System Panel Header / 1 x SPI TPM Header / 1 x Power LED and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 8 x Chassis Fan Connectors (4-pin)** / 3 x 24 pin ATX Power Connectors / 1 x 8 pin 12V Power Connector / 4 x 4 pin PCIe Power Connectors / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x Power Button / 1 x Reset Button*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.**CHA_FAN3~CHA_FAN8 supports the chassis fan of maximum 2.5A (30W) fan power.CPU_FAN1, CHA_FAN1 and CHA_FAN2 can adjust 4-pin fan speed.

Accessories

1 x SATA Data Cable / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse/Keyboard Port / 1 x HDMI Port / 2 x USB 2.0 Ports (Supports ESD Protection) / 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

Unique Feature

ASRock Super Alloy / Premium 50A Power Choke / Sapphire Black PCB / High Density Glass Fabric PCBASRock Steel SlotASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Fan Tachometer: CPU, Chassis Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis Fans / Fan Multi-Speed Control: CPU, Chassis Fans / Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V
