Chipset

Intel Q270

M.2-platser

1

Max minne

32 GB

PCIe-platser

1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* / 2 x PCI Express 3.0 x1 Slots* Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC662

Dimensioner

226 × 188mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

Three graphics output options: D-Sub, DVI-D and HDMI* / Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 30Hz / Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required) / Supports HDCP 2.2 with DVI-D and HDMI 1.4 Ports / Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port* Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.Supports up to 3 displays simultaneously

Övriga specifikationer

OS

Microsoft Windows 11 64-bit / 10 64-bit (For 9th, 8th and 7th Gen Intel CPU) / Microsoft Windows 11 64-bit / 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)* To install Windows 7 OS, a modified installation disk with xHCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions.

BIOS

128Mb AMI UEFI Legal BIOS with multilingual GUI support

Connector

1 x Print Port Header / 1 x COM Port Header / 1 x TPM Header / 1 x Chassis Intrusion and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)**** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.CHA_FAN1/WP and CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use.*** USB_7_8 is shared with USB32_3_4.

Accessories

1 x User Manual / 1 x I/O Shield / 2 x SATA Data Cables / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse/Keyboard Port / 1 x D-Sub Port / 1 x DVI-D Port / 1 x HDMI Port / 4 x USB 2.0 Ports (Supports ESD Protection) / 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

ASRock Super Alloy / Sapphire Black PCB / High Density Glass Fabric PCBASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Software and UEFI

Software / ASRock A-TuningUEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash / ASRock Internet Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
