Chipset

SOC

M.2-platser

2

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

SATA-portar

2

Ljudkodek

Realtek ALC269

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR4

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. / Four graphics output options: HDMI, DisplayPort, LVDS, D-Sub ports / Supports HDMI with max. resolution up to 4K@ 60Hz (HDMI x 1 port (Rear) )* (optional) Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz + HDMI x 1 port (Rear) / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports LVDS with max. resolution up to 1920x1080 @ 60Hz* (optional) Supports HDMI with max. resolution up to 4K@ 60Hz (HDMI x 1 port (Internal) ) / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required) / Supports HDCP 2.3 with HDMI 1.4 Port*Actual support may vary by CPU

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support

Connector

* (optional) 1 x Onboard TPM 2.0 (INFINEON SLB9672) / 1 x Chassis Intrusion Header / 1 x Panel Voltage Selection Header / 1 x Backlight Inverter Voltage Selection Header / 1 x FPD Brightness Header / 1 x Panel Off Header / 1 x LVDS Connector* (optional) 1 x HDMI2 (Internal) / 1 x CPU Fan Connector (4-pin)* / 1 x 4 pin 19V Power Connector (2-Pin) / 1 x Front Panel Audio Connector / 1 x Internal Speaker Header (4-Pin) / 1 x Digital MIC Header / 2 x SATA Power Connectors / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

Accessories

I/O Shield (optional) / 1 x SATA Data Cable (optional) / 1 x SATA Power Cable (optional) / 3 x Screws for M.2 Sockets / 1 x Standoff for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter) / 1 x D-Sub Port* (optional) 1 x DisplayPort 1.4 / 1 x HDMI Port: HDMI1 (Rear)* (optional) 1 x DisplayPort 1.4 + 1 x HDMI Port: HDMI1 (Rear) / 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection) / 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)* (optional) 2 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection) / 2 x USB 2.0 Ports (Support ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line out / Microphone

Unique Feature

ASRock Super Alloy / High Density Glass Fabric PCBASRock Full Spike Protection (for all USB, Audio, LAN Ports)

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
