Chipset

AMD Promontory B450

Max minne

64 GB

PCIe-platser

AMD Ryzen series CPUs (Vermeer, Matisse, Cezanne, Renoir, Summit Ridge and Pinnacle Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode) (Supports PCIe riser cards to extend one x16 slot to two x8 slots if you install AMD Ryzen series CPUs)* AMD Ryzen series CPUs (Picasso, Raven Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*AMD Athlon series CPUs / 1 x PCI Express 3.0 x16 Slot (PCIE1: x4 mode)* / 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac PCIe WiFi module (on the rear I/O) / 15μ Gold Contact in VGA PCIe Slot (PCIE1)*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC1220

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. Max Shared memory supports up to 16GB.** / Dual graphics output: Support HDMI and DisplayPort 1.2 by independent display controllers / Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz / Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI 2.0 monitor is required) / Supports HDCP 1.4 with HDMI 2.0 and DisplayPort 1.2 Ports / Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports*Actual support may vary by CPU**The Max shared memory 16GB requires 32GB system memory installed.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit**Summit Ridge do not officially support Windows 11.

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / CPU, DRAM, PCH 1.05V, PROM 2.5V, Voltage Multi-adjustment

Connector

1 x LPC Header / 1 x Addressable LED Header* / 1 x AMD Fan LED Header** / 1 x CPU Fan Connector (4-pin)*** / 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector (15μ Gold Audio Connector) / 1 x AMD LED Fan USB Header / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)*Supports in total up to 5V/3A, 15W LED Strip**The AMD Fan LED Header supports LED strips of maximum load of 3A (36W) and length up to 2.5M.***The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.CHA_FAN1/WP and CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

I/O Shield / 2 x SATA Data Cables / 2 x ASRock WiFi 2.4/5 GHz Antennas / 1 x Screw for M.2 Socket

Gaming Armor

Power / Hi-Density Power Connector (8 pin)Memory / 15μ Gold Contact in DIMM SlotsVGA Card / 15μ Gold Contact in VGA PCIe Slot (PCIE1)Internet / Intel LANCooling / 2oz Copper PCBAudio / Creative Sound Blaster Cinema 5

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x PS/2 Mouse/Keyboard Port / 1 x HDMI Port / 1 x DisplayPort 1.2 / 1 x Optical SPDIF Out Port / 2 x USB 2.0 Ports (Supports ESD Protection)* / 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) / 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection) / 2 x USB 3.1 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)*1 x Fatal1ty Mouse Port (USB 2.0) is included

Unique Feature

ASRock USB 3.1 Gen2 / ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s) / ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s)ASRock Super Alloy / Premium Power Choke / Dual-N MOSFET / Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) / Matte Black PCB / High Density Glass Fabric PCB / 2oz Copper PCBIntel 802.11ac WiFiASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Temperature Sensing: CPU, Chassis/Water Pump Fans / Fan Tachometer: CPU, Chassis/Water Pump Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans / Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

Software and UEFI

Software / ASRock F-Stream / ASRock Polychrome SYNC / ASRock Key MasterUEFI / ASRock Full HD UEFI / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
