Sockel

LGA 1851

Chipset

Intel B860

M.2-platser

2

Ethernet

2.5 Gigabit

Max minne

128 GB

PCIe-platser

1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module and Intel CNVi (Integrated WiFi/BT)

SATA-portar

2

Ljudkodek

Realtek ALC269

Dimensioner

140 × 147mm

Formfaktor

STX

Minnestyp

DDR5

Displayutgångar

Intel Xe LPG Graphics Architecture / Supports Quad Display (four 4K displays) and Triple Display (two 4K displays and one 8K display) / 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz / 2 x DisplayPort 1.4 with DSC (compressed), support HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz / 1 x Intel Thunderbolt 4, supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz***Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.**Only the CPU's embedded graphics can be displayed through Thunderbolt ports. If you want to display to a Thunderbolt monitor, please use CPU models with embedded graphics.

Max minneshastighet

7200 MHz

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

BIOS

128Mb AMI UEFI Legal BIOS with multilingual GUI support / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support / DRAM Voltage Multi-adjustment

RAID

Supports RAID 0 and RAID 1 for SATA storage devices

Connector

1 x Headphone/Headset Jack / 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) / 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (Supports ESD Protection) / 1 x Microphone Input Jack

Accessories

Quick Installation Guide, I/O Shield / 2 x SATA Data with Power Cable / 2 x Screws for M.2 Sockets / 1 x Screw for WiFi Module

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x DC Jack (Compatible with the 19V power adapter)* / 1 x HDMI Port / 2 x DisplayPort 1.4 / 1 x Thunderbolt 4 Type-C Port (40 Gb/s for USB4 protocol; 40Gb/s for Thunderbolt protocol)** / 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection) / 1 x RJ-45 LAN Port*Please use 120W power adapter for 65W CPU and 90W power adapter for 35W CPU.**Supports USB PD 3.0 up to 5V@3A (15W) charging

Unique Feature

Superb Productivity / PCIe Gen5 (M.2) / Dual Channel DDR5 / Thunderbolt 4 Type-C Ports (40 Gb/s)Ultrafast Connectivity / 2.5G LANEZ Update / ASRock Auto Driver Installer

Hardware Monitor

CPU Temperature Sensing / CPU Fan Tachometer / CPU Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU Fan Multi-Speed Control / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
