WiFi

WiFi 6

Sockel

LGA 1851

Chipset

Intel B860

M.2-platser

2

Ethernet

2.5 Gigabit

Max minne

128 GB

PCIe-platser

CPU: / 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*Chipset: / 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)* Supports NVMe SSD as boot disks

SATA-portar

3

Ljudkodek

Realtek ALC1220

Dimensioner

170 × 170mm

Formfaktor

Mini-ITX

Minnestyp

DDR5

Minnesplatser

2

Displayutgångar

Intel Xe LPG Graphics Architecture / 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz / 1 x Intel Thunderbolt 4, supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz*** Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.** Supports two 4K displays or one 8K display Only the CPU's embedded graphics can be displayed through Thunderbolt ports. If you want to display to a Thunderbolt monitor, please use CPU models with embedded graphics.

Max minneshastighet

9333 MHz

Övriga specifikationer

OS

Microsoft Windows 11 64-bit

USB

CPU: / 1 x Thunderbolt 4/USB4 Type-C (Rear)Chipset: / 1 x USB 3.2 Gen2 Type-C (Front) / 2 x USB 3.2 Gen2 Type-A (Rear) / 6 x USB 3.2 Gen1 (4 Rear, 2 Front) / 3 x USB 2.0 (1 Rear, 2 Front)* All USB ports support ESD Protection

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 5 for SATA storage devices

Connector

1 x Thermistor Cable Header / 2 x Addressable LED Headers* / 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)** / 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)** / 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) / 1 x Front Panel Audio Connector / 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) / 1 x USB 3.2 Gen1 Headers (Supports 2 USB 3.2 Gen1 ports) / 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)* Supports in total up to 5V/3A, 15W LED Strip** CPU_FAN and CHA_FAN1 support the fan power up to 1A (12W).*** AIO_PUMP supports the fan power up to 3A (36W). AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

2 x SATA Data Cables / 2 x ASRock WiFi 2.4/5/6 GHz Antennas / 1 x Thermistor Cable / 2 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 1 x Optical SPDIF Out Port / 1 x Thunderbolt 4/USB4 Type-C Port (40 Gb/s)* / 2 x USB 3.2 Gen2 Type-A Ports / 4 x USB 3.2 Gen1 Ports / 1 x USB 2.0 Port / 1 x RJ-45 LAN Port / 1 x BIOS Flashback Button / 1 x Line Out Jack (Gold Audio Jack) / 1 x Microphone Input Jack (Gold Audio Jack)* Supports USB PD 3.0 up to 5V@3A (15W) charging

Unique Feature

Superb Productivity / PCIe Gen5 (Graphics, M.2) / Dual Channel DDR5 / Thunderbolt 4/USB4 Type-C Port (40 Gb/s)Rock-Solid Durability / 10+1+1+1+1 Power Phase, 110A SPS for VCore with Enlarged Heatsink Armor / Memory OC Shield / Flexible Integrated I/O Shield / 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)Ultrafast Gaming / 2.5G LAN, 802.11axe Wi-Fi 6E ModuleEZ Update / BIOS Flashback Button / ASRock Auto Driver InstallerEZ Troubleshooter / ASRock Post Status Checker

Software and UEFI

Software / ASRock Motherboard Utility (Phantom Gaming Tuning) / ASRock Phantom Gaming LAN Software / ASRock Polychrome SYNC*UEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Auto Driver Installer / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
