Chipset

AMD Promontory B450

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

AMD Ryzen series CPUs (Vermeer, Matisse, Cezanne, Renoir, Summit Ridge and Pinnacle Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*AMD Ryzen series CPUs (Picasso, Raven Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*AMD Athlon series CPUs / 1 x PCI Express 3.0 x16 Slot (PCIE2: x4 mode)* / 1 x PCI Express 2.0 x1 Slot*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC887

Dimensioner

230 × 201mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. Max Shared memory supports up to 16GB.** / Three graphics output options: D-Sub, DVI-D and HDMI / Supports Triple Monitor / Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz / Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz / Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) / Supports HDCP 1.4 with DVI-D and HDMI Ports / Supports 4K Ultra HD (UHD) playback with HDMI Port*Actual support may vary by CPU**The Max shared memory 16GB requires 32GB system memory installed.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit**Summit Ridge do not officially support Windows 11.

BIOS

128Mb AMI UEFI Legal BIOS with GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / DRAM Voltage multi-adjustment

Connector

1 x COM Port Header / 1 x TPM Header / 1 x Chassis Intrusion and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 2 x Chassis Fan Connectors (1 x 3-pin, 1 x 4-pin)** / 1 x 24 pin ATX Power Connector / 1 x 4 pin 12V Power Connector / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.**The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power.

Accessories

I/O Shield / 2 x SATA Data Cables / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse/Keyboard Port / 1 x D-Sub Port / 1 x DVI-D Port / 1 x HDMI Port / 2 x USB 2.0 Ports (Supports ESD Protection) / 4 x USB 3.1 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

ASRock Super Alloy / High Density Glass Fabric PCB / Sapphire Black PCBASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

CPU/Chassis temperature sensing / CPU/Chassis Fan Tachometer / CPU/Chassis Quiet Fan / CPU/Chassis Fan multi-speed control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, Vcore

Software and UEFI

Software / ASRock A-TuningUEFI / ASRock Full HD UEFI / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
