Chipset

AMD Promontory B450

M.2-platser

1

Ethernet

1 Gigabit

Max minne

128 GB

PCIe-platser

AMD Ryzen series CPUs (Vermeer, Matisse, Cezanne, Renoir, Summit Ridge and Pinnacle Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)AMD Ryzen series CPUs (Picasso, Raven Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)AMD Athlon series CPUs / 1 x PCI Express 3.0 x16 Slot (PCIE1: x4 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode) / Supports AMD Quad CrossFireX and CrossFireX / 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac PCIe WiFi module (on the rear I/O)*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC892

Dimensioner

244 × 244mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

4

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* / DirectX 12, Pixel Shader 5.0 / Shared memory default 2GB. Max Shared memory supports up to 16GB.** / Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required) / Supports HDCP 1.4 with HDMI 1.4 Port / Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port*Actual support may vary by CPU**The Max shared memory 16GB requires 32GB system memory installed.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit**Summit Ridge do not officially support Windows 11.

BIOS

128Mb AMI UEFI Legal BIOS with multilingual GUI support / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / DRAM Voltage multi-adjustment

Connector

1 x Chassis Intrusion Header / 1 x Power LED and Speaker Header / 1 x RGB LED Header* / 1 x Addressable LED Header** / 1 x AMD Fan LED Header*** / 1 x CPU Fan Connector (4-pin)**** / 1 x Chassis Fan Connector (3-pin)***** / 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 1 x AMD LED Fan USB Header / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)*Supports in total up to 12V/3A, 36W LED Strip**Supports in total up to 5V/3A, 15W LED Strip***The AMD Fan LED Header supports LED strips of maximum load of 3A (36W) and length up to 2.5M.****The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.*****The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power.******The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.

Accessories

I/O Shield / 2 x SATA Data Cables / 2 x ASRock WiFi 2.4/5 GHz Antennas / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

2 x Antenna Ports / 1 x HDMI Port / 2 x USB 2.0 Ports (Supports ESD Protection) / 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

ASRock Super Alloy / Premium 42A Power Choke / Sapphire Black PCB / High Density Glass Fabric PCB / 2oz Copper PCBIntel 802.11ac WiFiASRock Ultra M.2 (PCIe Gen3 x4)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

Temperature Sensing: CPU, Chassis, Chassis/Water Pump Fans / Fan Tachometer: CPU, Chassis, Chassis/Water Pump Fans / Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis, Chassis/Water Pump Fans / Fan Multi-Speed Control: CPU, Chassis, Chassis/Water Pump Fans / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, Vcore

Software and UEFI

Software / ASRock A-Tuning / ASRock Polychrome SYNCUEFI / ASRock Full HD UEFI / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
