Chipset

Intel B250

M.2-platser

2

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

2 x PCI Express 3.0 x16 Slots (PCIE1: x16 mode; PCIE3: x4 mode)* / 1 x PCI Express 3.0 x1 Slot (Flexible PCIe)** / 1 x PCI Slot** / Supports AMD Quad CrossFireX and CrossFireX*Supports NVMe SSD as boot disks**If PCIE2 slot or PCI slot is occupied, the PCIe-type M.2 device on M2_1 socket will run at Gen3 x2 (16 Gb/s).

SATA-portar

6

Ljudkodek

Realtek ALC892

Dimensioner

244 × 244mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

4

Displayutgångar

Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics / Gen9 LP, DX11.3, DX12 / HWA Encode/Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU) / HWA Encode/Decode: VP8, HEVC 8b; GPU/SWEncode/Decode: VP9, HEVC 10b (For 6th Gen Intel CPU) / Max. shared memory 1024MB* The size of maximum shared memory may vary from different operating systems. / Four graphics output options: D-Sub, DVI-D, HDMI and DisplayPort 1.2 / Supports Triple Monitor / Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz / Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) / Supports HDCP with DVI-D, HDMI and DisplayPort 1.2 Ports / Supports Full HD 1080p Blu-ray (BD) playback with DVI-D, HDMI and DisplayPort 1.2 Ports*Intel HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit (For 7th Gen Intel CPU) / Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)*To install Windows 7 OS, a modified installation disk with xHCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions.For the updated Windows 10 driver, please visit ASRock's website for details.

BIOS

128Mb AMI UEFI Legal BIOS / ACPI 6.0 Compliant wake up events / SMBIOS 2.7 Support / CPU, GT_CPU, DRAM, PCH 1.0V, VCCIO, VCCSA, VCCST Voltage Multi-adjustment

Connector

1 x Buzzer / 1 x Onboard TPM 2.0 / 1 x Print Port Header / 2 x COM Port Headers / 1 x Chassis Intrusion and Speaker Header / 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)* / 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.**CHA_FAN1 and CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.

Accessories

Support CD, I/O Shield / 2 x SATA Data Cables / 2 x Screws for M.2 Sockets

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse Port / 1 x PS/2 Keyboard Port / 1 x D-Sub Port / 1 x DVI-D Port / 1 x HDMI Port / 1 x DisplayPort 1.2 / 2 x USB 2.0 Ports (Supports ESD Protection) / 3 x USB 3.1 Gen1 Type-A Ports (Supports ESD Protection) / 1 x USB 3.1 Gen1 Type-C Port (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

ASRock Super Alloy / Premium 50A Power Choke / Sapphire Black PCB / High Density Glass Fabric PCBASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) TechnologyASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)ASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

CPU, Chassis temperature sensing / CPU, Chassis Fan Tachometer / CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) / CPU, Chassis Fan multi-speed control / CASE OPEN detection / Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V

Software and UEFI

Software / ASRock APP ChargerUEFI / ASRock EZ Mode / ASRock Full HD UEFI / ASRock My Favorites in UEFI / ASRock Instant Flash / ASRock Internet Flash / ASRock Crashless BIOS / ASRock UEFI Tech Service*These utilities can be downloaded from ASRock Live Update & APP Shop.
