Sockel

AM4

Chipset

AMD Promontory B350

Ethernet

1 Gigabit

Max minne

64 GB

PCIe-platser

AMD Ryzen series CPUs (Matisse, Summit Ridge and Pinnacle Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)AMD 7th A-Series APUs / 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)AMD Ryzen series CPUs (Picasso, Raven Ridge) / 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)AMD Athlon series CPUs / 1 x PCI Express 3.0 x16 Slot (PCIE2: x4 mode)* / 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode) / 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode) / 2 x PCI Express 2.0 x1 Slots (PCIE1: x1 mode; PCIE3: x1 mode) / 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC892

Dimensioner

244 × 244mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

4

Displayutgångar

Integrated AMD Radeon R-Series Graphics in A-series APU* / DirectX 12, Pixel Shader 5.0 / Max. shared memory 2GB / Three graphics output options: D-Sub, HDMI and DisplayPort 1.2 / Supports Triple Monitor / Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz / Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz / Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz / Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) / Supports HDCP 1.4 with HDMI and DisplayPort 1.2 Ports / Supports Full HD 1080p Blu-ray (BD) playback with HDMI and DisplayPort 1.2 Ports*Actual support may vary by CPU

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit**Bristol Ridge and Summit Ridge do not officially support Windows 11.

BIOS

128Mb AMI UEFI Legal BIOS / Supports "Plug and Play" / ACPI 5.1 compliance wake up events / Supports jumperfree / SMBIOS 2.3 support / DRAM Voltage multi-adjustment

Connector

1 x Print Port Header / 1 x COM Port Header / 1 x TPM Header / 1 x Power LED and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin) (Smart Fan Speed Control)** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 1 x AMD LED Fan USB Header / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) / 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.**CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.

Accessories

I/O Shield / 2 x SATA Data Cables / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse Port / 1 x PS/2 Keyboard Port / 1 x D-Sub Port / 1 x HDMI Port / 1 x DisplayPort 1.2 / 2 x USB 2.0 Ports (Supports ESD Protection) / 4 x USB 3.1 Gen1 Ports (Supports ESD Protection) / 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

ASRock Super Alloy / Premium 42A Power Choke / Sapphire Black PCB / High Density Glass Fabric PCB / 2oz Copper PCBASRock Full Spike Protection (for all USB, Audio, LAN Ports)ASRock Live Update & APP Shop

Hardware Monitor

CPU, Chassis temperature sensing / CPU, Chassis Fan Tachometer / CPU, Chassis Quiet Fan / CPU, Chassis Fan multi-speed control / Voltage monitoring: +12V, +5V, +3.3V, Vcore

Software and UEFI

Software / ASRock A-Tuning / ASRock APP ChargerUEFI / ASRock Full HD UEFI / ASRock Instant Flash / ASRock Easy RAID Installer*These utilities can be downloaded from ASRock Live Update & APP Shop.
