Chipset

AMD A520

M.2-platser

1

Max minne

64 GB

PCIe-platser

CPU: / 1 x PCIe 3.0 x16 Slot (PCIE2), supports x16 mode*Chipset: / 2 x PCIe 3.0 x1 Slots (PCIE1 and PCIE3)* / 1 x PCI Slot*Supports NVMe SSD as boot disks

SATA-portar

4

Ljudkodek

Realtek ALC897

Dimensioner

244 × 201mm

Formfaktor

Micro ATX

Minnestyp

DDR4

Minnesplatser

2

Displayutgångar

Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU (Actual support may vary by CPU) / 1 x HDMI 2.1, supports HDR, HDCP 2.3, 4K Ultra HD (UHD) playback and max. resolution up to 4K 60Hz / 1 x DisplayPort 1.4, supports HDCP 2.3, 4K Ultra HD (UHD) playback and max. resolution up to 5K 120Hz* / 1 x DVI-D, supports max. resolution up to Full HD (1920x1200) 60Hz* / 1 x D-Sub, supports max. resolution up to Full HD (1920x1200) 60Hz**Only DVI-D will function if DVI-D and DisplayPort 1.4 ports are both connected.

Övriga specifikationer

OS

Microsoft Windows 10 64-bit / 11 64-bit

USB

6 x USB 3.2 Gen1 (4 Rear, 2 Front) / 6 x USB 2.0 (2 Rear, 4 Front)*All USB ports support ESD Protection

BIOS

128Mb AMI UEFI Legal BIOS with GUI support

RAID

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

Connector

1 x Print Port Header / 1 x SPI TPM Header / 1 x COM Port Header / 1 x Chassis Intrusion and Speaker Header / 1 x CPU Fan Connector (4-pin)* / 1 x Chassis Fan Connector (4-pin)** / 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** / 1 x 24 pin ATX Power Connector / 1 x 8 pin 12V Power Connector / 1 x Front Panel Audio Connector / 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) / 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)*CPU_FAN1 supports the fan power up to 1A (12W).**CHA_FAN2 supports the fan power up to 1A (12W).***CHA_FAN1/WP supports the fan power up to 2A (24W).CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.

Accessories

1 x User Manual / 1 x I/O Shield / 2 x SATA Data Cables / 1 x Screw for M.2 Socket

Certifications

FCC, CE / ErP/EuP ready (ErP/EuP ready power supply is required)

Rear Panel I/O

1 x PS/2 Mouse Port / 1 x PS/2 Keyboard Port / 1 x Serial Port: COM2 / 1 x D-Sub Port / 1 x DVI-D Port / 1 x HDMI Port / 1 x DisplayPort 1.4 / 2 x USB 2.0 Ports / 4 x USB 3.2 Gen1 Ports / 1 x RJ-45 LAN Port / HD Audio Jacks: Line in / Front Speaker / Microphone

Unique Feature

Rock-Solid Durability / 6 Power Phase

Software and UEFI

Software / ASRock Motherboard Utility (A-Tuning)UEFI / ASRock Full HD UEFI / ASRock Instant Flash*These utilities can be downloaded from ASRock Live Update & APP Shop.
