Typ

Fan

Vikt

0.328 kg

Luftflöde

370 m3/h

Fläktstorlek

120 mm

Antal fläktar

1

Fläktmodell

S12038-8K

Garanti

6 Years

Dimensioner

120 L x 120 W x 38 H mm

Lagertyp

Dual Ball Bearing with Brass Housing

Statiskt tryck

37 mmH2O

Övriga specifikationer

Flammability UL 94

V-0

Fan Specifications: Speed

800-8000 rpm, PWM controlled

Fan Specifications: Connector

2510 4-Pin Fan Connector

Operating Ambient Temperature

-10°C~70°C

Fan Specifications: Cable Length

300 mm, Black

Fan Specifications: Start-Up Voltage

6.5 V DC

Fan Specifications: Current (Maximum)

3.2 A

Fan Specifications: Current | Voltage

2.2 A | 12.0 V DC

Fan Specifications: Motor Protection Features

Reverse Polarity Protection, Over Voltage Protection, Over Current Protection
