Typ

AIO 360mm

Vikt

1.84 kg

Luftflöde

95.65 m3/h

Fläktstorlek

120 mm

Antal fläktar

3

Fläktmodell

3x P12 PWM

Fläkthastighet

200-1800 RPM

Material

Aluminium, Copper, Micro Skived Fins

Garanti

6 Years

Pumphastighet

800-2800 RPM

Dimensioner

398 L x 120 W x 38 H mm

Slanglängd

450 mm

Lagertyp

Fluid Dynamic Bearing

Radiatorstorlek

360 mm

Pumpkontakt

4-Pin PWM Connector

Statiskt tryck

2.2 mmH2O

Sockelkompatibilitet

1851, 1700, AM5, AM4

Övriga specifikationer

TIM

MX-6 (0.8 g)

PI | NNPI

338 | 309

Splitt Connector

3x 4-Pin PWM Connector

Fan Specifications: Connector

4-Pin PWM Connector

Operating Ambient Temperature

0-40 °C

Fan Specifications: Cable Lenght

40 mm

Pump Specifications: Tube Diameter

Outer: 12.4 mm

VRM Module Specifications: VRM Fan

400-2500 rpm (PWM controlled)

Fan Specifications: Current | Voltage

0.10 A | 12 V DC

Pump Specifications: Current | Voltage

0.35 A | 12 V DC

VRM Module Specifications: Current | Voltage

0.05 A | 12 V DC
