Vikt

3.66 kg

Front I/O

Power, LED Control Button, USB 3.0 x 1, USB 2.0 x 2, MIC/HD-AUDIO

Chassityp

Mid Tower

Material

Steel + Plastic

Dimensioner

438 × 193 × 463 mm

Formfaktor

ATX, Micro-ATX, Mini-ITX

Max 120 mm-fläktar

9

Max 140 mm-fläktar

0

2.5"-fack

4

3.5"-fack

2

Max GPU-längd

355 mm

Max PSU-längd

190 mm

Sidopanel

Tempered Glass

Expansionsplatser

7

Max kylarhöjd

155 mm

Radiatorstöd (topp)

120 mm

Radiatorstöd (front)

240 mm

Övriga specifikationer

Rear

1 x 120 mm

UPC#

0-761345-81002-9 (NX201) | 0-761345-81003-6 (NX201 RGB)

Warranty

1 Year

Dust Filter

Top / Bottom

Gross Weight

4.55 KG (NX201) / 4.55 KG (NX201 RGB)

Power supply

2 x 120 mm

Included Fan(s)

1 x 120mm regular fan in rear (NX201) | 1 x 120mm RGB fixed mode fan in rear (NX201 RGB)

Miscellaneous UPC#

0-761345-81002-9 (NX201) | 0-761345-81003-6 (NX201 RGB)

Miscellaneous Warranty

1 Year

Clearance Max GPU Length

≤ 355 mm

Clearance Max PSU Length

≤ 190 mm

Miscellaneous Net Weight

3.66 KG (NX201) / 3.66 KG (NX201 RGB)

Miscellaneous Dust Filter

Top / Bottom

Miscellaneous Gross Weight

4.55 KG (NX201) / 4.55 KG (NX201 RGB)

Expansion & Drive Bays 2.5"

2

Case Specification Materials

Steel + Plastic

Case Specification Dimensions

438 x 193 x 463 mm (DWH)

Case Specification Side Panel

Tempered glass

Case Specification Form Factor

Mid Tower

Clearance Max CPU Cooler Height

≤ 155 mm

Expansion & Drive Bays 3.5" /2.5"

2/2

Case Specification Mainboard Support

ATX, Micro-ATX, ITX

Expansion & Drive Bays Expansion Slots

7

Case Specification Front Access & Controls

Power, LED Control Button, USB 3.0 x 1, USB 2.0 x 2, MIC/HD-AUDIO
