Vikt

2.24 kg

Fläktstorlek

120 mm

Modulär

Semi

Effekt

750 W

Garanti

7 years

ATX-version

ATX 12

Effektivitet

80+ Gold

Formfaktor

ATX

Skydd

OCP/OVP/UVP/SCP/OPP/ | OTP/SIP/NLO

EPS-kontakter

2

SATA-kontakter

8

PCIe 8-pin-kontakter

4

Övriga specifikationer

PFC

Active PFC (>0.9 typical)

UPC#

0-761345-11629-9 EA750G PRO White EC | 0-761345-11627-5 EA750G PRO White GB | 0-761345-11363-2 EA750G PRO White

Model

EA750G PRO White

Dimension

140 x 150 x 86 mm (LWH)

Efficiency

92% Typically

Regulatory

cTUVus/TUV/CB [IEC62368 Compliant]/RCM/CE/ | EAC/CCC/BSMI/FCC

Gross Weight

3.22Kg

Input Current

10A-5A

Input Voltage

100-240 VAC

Power Good Signal

100-500ms

Input Frequency Range

50Hz-60Hz

Operation Temperature

0~40°C

Case Specification Fan

120mm Silence Fan

Case Specification PFC

Active PFC (>0.9 typical)

Case Specification Type

ATX 12V 2.4

Case Specification UPC#

0-761345-11629-9 EA750G PRO White EC | 0-761345-11627-5 EA750G PRO White GB | 0-761345-11363-2 EA750G PRO White

Case Specification Model

EA750G PRO White

Case Specification Modular

Semi-Modular

Case Specification Warranty

7 years

Case Specification Connector

1 x MB 24(20+4) Pin | 2 x 8(4+4) Pin EPS 12V | 4 x 8(6+2) Pin PCI-E | 8 x SATA | 3 x Molex

Case Specification Dimension

140 x 150 x 86 mm (LWH)

Case Specification Efficiency

92% Typically

Case Specification Net Weight

2.24Kg

Case Specification Protection

OCP/OVP/UVP/SCP/OPP/ | OTP/SIP/NLO

Case Specification Regulatory

cTUVus/TUV/CB [IEC62368 Compliant]/RCM/CE/ | EAC/CCC/BSMI/FCC

Case Specification Gross Weight

3.22Kg

Case Specification Input Current

10A-5A

Case Specification Input Voltage

100-240 VAC

Case Specification Certifications

80 Plus Gold

Case Specification Output Capacity

750W

Case Specification Power Good Signal

100-500ms

Case Specification Input Frequency Range

50Hz-60Hz

Case Specification Operation Temperature

0~40°C
